A circle diagram can contain several lengths on one line. Power-of-a-point relationships use particular products, so labelling external and whole lengths prevents a common substitution error.
Need help choosing a next step? Scan the contact QR code below or contact Hanlin on WeChat. Send AMC12 SECANT 1025 and tell us your school year and question.
Specify the configuration
From a point P outside a circle, a secant meets the circle first at A and then B. Suppose PA = 9 and PB = 16. A tangent from P touches the circle at T.
The tangent-secant theorem gives PT2 = PA × PB = 144, so the tangent length is PT = 12.
Identify the internal segment
The inside part AB is PB - PA = 7. It is not the second factor in this theorem. Using 9 × 7 would confuse the whole secant with its internal part.
All lengths must refer to the same external point P and the actual circle configuration.
Check applicability before multiplying
If the point were inside the circle, the diagram and relevant segment relationship would need reinterpreting. A theorem name alone does not establish its conditions.
Mark P-A-B in order before writing the product, and choose the positive root because a segment length is positive. This original example supports AMC 12 geometry reasoning and is not a released MAA problem.
